| Size:3060(L) x 1250(W) x 1550(H) mm |
| Inlet height 800mm ±50mm，Outlet height 1100mm ±50mm |
| Conveyor rail:3500
mm |
| Solder pot:750(L) x 450(W) x 220(H) mm |
| Timer:weekly timer |
Pre-heater: One sets two section contion control,12pcs ceramic tube total lenght500
mm
|
| Exhaust:8" x2 |
| PCSize350 mm |
| Weight:1550Kg |
|
出口輸送馬達.冷卻風扇.反射罩 |
| Typ
\ Model |
SEL-350-CA |
| Power |
3ψ or 1ψ 220V 21.5KW 80A |
| Prudction |
8Hours |
2,200 PCS |
| PCBSize |
250 x300 mm |
| Conveyo |
Speed |
0 ~ 2400 mm/min. |
| Tilting Angle |
3°~4.5° |
| Bubble Flux Tank |
Flux Capacity |
8L |
| Air Pressure |
1.5Kg/cm2 |
| Preheater |
Power Consumption |
9KW x 2 , 25A x 2 |
| Temperature Range |
0℃~599℃ |
| Solder Pot |
Power Consumption |
10.8KW |
| Temperature Range |
0℃~399℃ |
| Nozzle |
0 ~ 400 mm |
| Flow Height |
0 ~ 12 mm |
| Solder Capacity |
450Kg |
| Motor |
Panasonic 90W x 2 |
| Weight |
about1,550Kg |
|
寬窄採用密閉式滾珠杆及懸吊式覆軌 |
控制面板 |
|
